              Above ground Poolcover-System
              TYPE LIGHT

              Construction: Roller system mounted on the edge of the pool
              Installation: New or subsequent fitting
              Maximum size: 6 m x 12 m; for larger pools, a Compact type unit should be used.
              Drive units: Side sections semi-circular or rectangular
              Cover slats: Light slats 60 mm wide and 10 mm thick
              Guidelines: Installation approved for private and public swimming pools
          • Compact
            • /wp-content/uploads/sites/2/04_08_grando_Compact_above-ground_cover_automatic_0183.mp4

              Above ground Poolcover-System
              TYPE COMPACT

              Construction: Roller system mounted on the edge of the pool
              Installation: New or subsequent fitting
              Maximum size: 50 m x 25 m (larger sizes depending on pool shape)
              Where the pool width is larger than 12,50 m, we recommend a cover divided in two.
              Drive unit:
              		 Drive unit mounted on the side
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved for private and public pools
          • Mobile
            • /wp-content/uploads/sites/2/04_09_grando_mobile_wheeled_above-ground_cover_automatic_0184.mp4

              Above ground Poolcover-System
              TYPE MOBILE

              Construction: The entire roller system is mounted on rollers and can, when required, be moved manually or electrically on permanently mounted guide rails
              Installation: New or subsequent fitting
              Maximum size: 50 m x 25 m (larger sizes depending on pool shape). Where the pool width is larger than 12.50 m, we recommend a cover divided into two
              Drive unit:

              		 Drive unit mounted on the side
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved for private and public swimming pools
      • Below Ground Poolcovers
          • IBS-1
            • /wp-content/uploads/sites/2/04_10_grando_IBS-1_below-ground_poolcover_automatic_0185.mp4

              Below ground poolcover-system
              TYPE IBS-1

              Construction: Roller system mounted above the bottom of the pool
              Installation: New and subsequent fitting
              Maximum size: 25 m x 50 m (larger sizes depending on pool shape) From a pool width of 12.50 m, we recommend a cover divided into two
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit: Tubular motor (not always possible, dependent on pool width and depth)
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved only for private pools
          • IBS-2
            • /wp-content/uploads/sites/2/04_11_grando_IBS-2_below-ground_poolcover_Graeting_electric_0186.mp4

              Below ground poolcover-system
              TYPE IBS-2

              Construction: Roller system in the pit below the bottom of the pool
              Installation: New construction
              Maximum size: 25 m x 50 m (larger sizes depending on the pool shape). From a pool width of 12.50 m, we recommend a cover divided into two.
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit: Tubular motor (not always possible, dependent on pool width and depth)
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved only for private pools
          • IBS-3
            • /wp-content/uploads/sites/2/04_12_grando_IBS-3_below-ground_poolcover_automatic-shaft-clapper_0187.mp4

              Below ground poolcover-system
              TYPE IBS-3

              Construction: The roller system is mounted in the pit below the bottom of the pool with an automatic shutter
              Installation: New construction
              Maximum size: 25 m x 50 m (larger sizes depending on the pool shape). From a pool width of 12.50 m, we recommend a cover divided into two
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit: Not possible
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved for private and public swimming pools
          • IBS-4
            • /wp-content/uploads/sites/2/04_13_grando_IBS-4_below-ground_pool-cover_electric_0188.mp4

              Below ground poolcover-system
              TYPE IBS-4

              Construction: Mounted directly below the surface of the water
              Installation: New or retrofitting
              Maximum size: 25 m x 50 m (larger sizes depending on the pool shape).
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit: Tubular motor (not always possible, dependent on pool width)
              Cover-slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved only for private pools
          • IBS-5
            • /wp-content/uploads/sites/2/04_14_grando_IBS-5_below-ground_pool-cover_electric_0189.mp4

              Below ground poolcover-system
              TYPE IBS-5

              Construction: Roller system let into the wall of the pool with a front panel. The water level is below the top of the pit.
              Installation: New construction
              Maximum size: 25 m x 50 m (larger sizes depending on the pool shape). From a pool width of 12.50 m, we recommend a cover divided into two.
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit: Tubular motor (not always possible, dependent on pool width and depth)
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved only for private pool
          • IBS-6
            • /wp-content/uploads/sites/2/04_15_grando_IBS-6_below-ground_pool_cover_rigid_electric_panel_0190.mp4

              Below ground poolcover-system
              TYPE IBS-6

              Construction: Roller system let into the wall of the pool with a front panel. Because the water level is above the top of the pit, guide rollers are built into the cover pit
              Installation: New construction
              Maximum size: 25 m x 50 m (larger sizes depending on the pool shape). From a pool width of 12.50 m, we recommend a cover divided into two
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit: Tubular motor (not always possible, dependent on pool width and depth)
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved only for private pools
          • IBS-8
            • /wp-content/uploads/sites/2/04_16_grando_IBS-8_below-ground_pool-cover_automatic-shaft-clapper_0191.mp4

              Below ground poolcover-system
              TYPE IBS-8

              Construction: Roller system mounted below the bottom of the pool with one shaft and for two covers. With automatic shutter
              Installation: New construction
              Maximum size: 25 m x 50 m (larger sizes depending on the pool shape). From a pool width of 12.50 m, we recommend a cover divided into two
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit:  Not possible
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved for private and public swimming pools
          • IBS-9
            • /wp-content/uploads/sites/2/04_17_grando_IBS-9_below-ground_pool_cover_well_electric_0192.mp4

              Below ground poolcover-system
              TYPE IBS-9

              Construction: The roller system is accommodated in a separate pit behind the pool. The pit is filled with water and connected to the pool through a gap
              Installation: New construction
              Maximum size: 25 m x 50 m (larger sizes depending on the pool shape). From a pool width of 12.50 m, we recommend a cover divided into two.
              Drive unit in separate motor pit: Drive unit mounted on the shaft or chain drive
              Drive unit without motor pit: Tubular motor (not always possible, dependent on pool width and depth)
              Cover slats: Standard slats 60 mm wide and 14 mm thick
              Guidelines: Installation approved only for private pools
